• Material: Rubber, nylon, polyurethane (PU), polyvinyl chloride (PVC), metal wires...
  • Compatible models: Belt conveyor(B400/500/650/800/1200/1400/1600...)
  • Application scope: Widely used in industries such as metallurgy, mining, coal, ports, transportation, hydropower, and chemical engineering for loading, unloading, transferring, or stacking various bulk materials or bulk items with a loose density of 500 to 2500 kg/m3 under normal temperature conditions.
  • introduction
  • Technical parameters
  • Goods Delivery
Related Cases

A conveyor belt is a widely used conveying equipment in industrial production, and it comes in various materials. Different conveyor belt materials have distinct characteristics and applications. Choosing the right conveyor belt material can improve production efficiency and reduce costs.
Rubber Conveyor Belt: Rubber conveyor belts are the most common type of belts. They are composed of multiple layers of rubber and fiber materials. Rubber conveyor belts offer excellent flexibility and tensile strength, making them suitable for transporting heavy loads. They have good wear resistance, high-temperature resistance, and corrosion resistance. Rubber conveyor belts find extensive use in industries like mining, ports, and construction materials.
PVC Conveyor Belt: PVC conveyor belts are made from polyvinyl chloride (PVC). They are lightweight, have good wear resistance, and high tensile strength. The smooth surface of PVC belts resists material adhesion, making them easy to clean. PVC conveyor belts are widely used in food processing, pharmaceuticals, light industries, and places where cleanliness and hygiene are essential.
PU Conveyor Belt: PU conveyor belts are made from polyurethane (PU). They offer excellent tensile strength and wear resistance, making them suitable for high-tension and high-speed conveying. PU belts have a smooth surface, resist deformation, and exhibit good stability. They are commonly used in electronics, automotive, and machinery manufacturing industries, especially for conveying medium to heavy materials and in precision transmission applications.
Nylon Conveyor Belt: Nylon conveyor belts are primarily made from nylon fibers. They have high strength, high tensile modulus, good wear resistance, and tensile strength. Nylon belts are resistant to oil and solvents, making them suitable for use in high-temperature and harsh conditions. They are widely used in metallurgy, chemical, and glass industries, especially for long-distance and high-load conveying.
Metal Mesh Conveyor Belt: Metal mesh conveyor belts are woven from metal wires, offering high strength, corrosion resistance, and high-temperature resistance. They can withstand high temperatures, corrosive materials, and heavy loads. Metal mesh conveyor belts are extensively used in drying, sintering, and heat treatment applications, especially in environments where ventilation and cooling are necessary.
Conveyor belts for conveyor systems come in a variety of materials, each with its unique characteristics and suitable applications. When choosing a conveyor belt for your conveyor system, you should consider specific requirements and conditions to ensure you select the right one.

Contact us to visit the factory or order products

Rubber/Nylon Belt Specification

Width(mm) Belt material No. of ply Thickness of upper rubber
Thickness of lower rubber
Percentage of natural rubber
500 CC-56 4 4.5 1.5 >12%
650 CC-56 4 4.5 1.5 >12%
800 CC-56 4 4.5 1.5 >12%
1000 NN-100 5 6.0 2.0 >12%
1200 NN-100 5 6.0 2.0 >12%
1400 NN-100 6 6.0 3.0 >12%

Belt Frame Specification

Belt width
Material of main structure
(Hot Rolling U-Steel)
Material of crossbeam
(Hot Rolling Angle Steel)
500 140x58x6.0 50x50x5.0 Steel Tube(External Diameterφ89-108, Thickness>4.0-4.5)
650 140x58x6.0 50x50x5.0 Steel Tube(External Diameterφ89-108, Thickness>4.0-4.5)
800 160x63x6.5 63x63x6.0 Steel Tube(External Diameterφ89-108, Thickness>4.0-4.5)
1000 180x68x7.0 80x80x8.0 Steel Tube(External Diameterφ108-133, Thickness>4.5-5.0)
1200 180x68x7.0 80x80x8.0 Steel Tube(External Diameterφ108-133, Thickness >4.5-5.0)
1400 220x79x9.0 90x90x8.0 Steel Tube(External Diameterφ133-159, Thickness>5.0-5.5)

Note: Our products are being updated constantly, all rights reserved by EVERED.
